Outline Input Channels Microphone 1 - Combo (Mic, +48 V phantom power), 3.5 mm (1/8") mini (Headset mic, Plug-in power) *Mic and Headset mic cannot be used simultaneously Smartphone 1 - 4-pole mini input/output (TRRS) HDMI 1 - Switchable input HDMI 1 or HDMI 2 by button; Audio input: 2ch 24-bit/192kHz (Max.), Video signal *1: No video capture function USB 2 - Virtual devices (Voice, Streaming) Output Channels PHONES 1 - 3.5 mm (1/8") stereo mini (Headphones or Headset phones) Smartphone 1 - 4-pole mini input/output (TRRS) MONITOR OUT 1 - Stereo mini (Speaker out) HDMI 1 - Audio out: 2ch 24-bit/48kHz fixed, Video signal *1: Pass-through USB 2 - Virtual devices (Voice, Speaker) Functions MUTE button x 1, HDMI input select button x 1, Monitor output select button x 1, Effect preset button x 6 (Voice x 3, Game x3) On-board processors DSP ZG SURROUND, FOCUS MODE/EQ, 3D VOICE CHAT, Voice change/Game sound effects *Detail is operated on ZG Controller USB USB Audio Sampling Frequency: Max. 48 kHz, Bit Depth: 24-bit, Type-C USB DC Power input 1 - Type-C, 5 V DC, 1.5 A General specifications Power requirements 5 V DC, 1.5 A Power consumption Max. 7.5 W Dimensions W 195 mm (7.7") H 47.5 mm (1.9") D 110 mm (4.3") Net weight 0.8 kg (1.8 lbs) Included Accessories USB 2.0 cable (USB-C to USB-C) 1.5 m x 1, USB 2.0 cable (USB-A to USB-C) 1.5 m x 1, Start Guide, Safety Guide Others Operating Temperature: 0 to + 40 ℃ *1 - Video format: VGA, 480i (60 Hz), 576i (50 Hz), 480p (60 Hz), 576p (50 Hz), 720p (60 Hz, 50 Hz), 1080i (60 Hz, 50Hz), 1080p (60 Hz, 50 Hz, 30Hz, 25 Hz, 24 Hz), 4K (60 Hz, 50 Hz, 30 Hz, 25 Hz, 24 Hz YH-G01 General specifications Frequency Response 20 Hz - 20 kHz Impedance 35 Ω Sensitivity (SPL) 94.4 dB/mW Microphone Electret condenser microphone Connector 3.5 mm (1/8"), 4-pole stereo mini (TRRS) Cable 2 m Weight Approx. 240 g (0.5 lbs) (without cable&plug) Included Accessories Microphone x 1, Headset audio splitter cable x 1, Owner’s manual
